Single axis scanning stages

An easy way to add motion to your measurement process

Do you need to scan your sensor over your part’s surface to capture area or profile data? Our single axis stage kits offer a quick and easy way to integrate your sensor with motion control.

Surface profile coverage

You need to scan over a larger area. Our motorized stages and motion controller connect to the sensor controller and enable larger area scanning.

Pre-configured stage kits

Don't have the in-house capabilities or time to select and implement the right motion control equipment?. We supply all of the necessary hardware to get you up and running quickly.

Easy installation

Our equipment is thoughtfully designed to be plug-and-play with the sensor controller. Take the easy route this time and get a kit that works.

Flexible operation

Programmable scan lengths and speeds allow for a variety of scan properties to be used while measuring your surfaces. Built-in flexibility offers the ability to scan a wide range of surfaces.

-SA

Single Axis Stages

These stages are sent as kits to help get surface measurement data over a larger area quickly. Our customers look to us to supply all of the stage hardware and installation support needed to integrate with a measurement sensor’s controller. This allows them to focus on more important projects within their businesses.

Don’t waste the time sourcing all of these components separately. Take the easy route with one of our ready-made kits. The kits include everything you need to obtain longer scans over the surfaces of your critical parts.

We’ve made it easy to purchase these kits by making them available online through our distribution partnership with Motion Plus.

How do these kits work?

These motorized stages accurately position the surface being scanned and trigger the sensor controller to take measurement data at fixed distances.  The stage controller is programmable for scan length and speed.

Cables that share stage position data and program signals are provided, and are plug-and-play with the sensor’s controller.

The operator loads the part, clicks “run” in the motion controller software, and waits until the scan has completed. The sensor data is captured and displayed automatically.

Kit contents

Data integrity

It is critical to understand the effects of introducing additional hardware into the measurement process. Here are the qualifications that our stage kits meet.
